ECS2310FP: 8-Port 114W PoE+ Switch
Provides exceptional PoE+ power delivery, fiber uplink, and seamless cloud management
EnGenius Cloud Managed 8-Port Gigabit PoE+ Switch ECS2310FP delivers reliable power and performance with 8 x GbE PoE+ ports (130W budget), 2 x SFP uplink ports, and a 20 Gbps switching capacity. Designed for enterprise deployments, this compact switch simplifies IP camera, Access Point, and VoIP installation with flexible Layer 2 features and centralized cloud management.
Shipping & Returns
Not satisfied? We allow returns within 14 days of product purchase
Management
This product is compatible with the EnGenius Cloud line of products
2-Year Warranty
Leave the worrying to us. We've got you covered on your hardware purchase.
Specifications
- High-Power Gigabit PoE+ & SFP Uplinks: Features 8 x Gigabit PoE+ ports with a 130W power budget and 2 x SFP fiber uplink ports to reliably power IP cameras, access points, and VoIP systems.
- Smart EnGenius Cloud Management: Effortlessly deploy, monitor, and manage your network anytime, anywhere via the license-free EnGenius Cloud portal and mobile app with real-time visual insights.
- Enterprise L2 Features & Flexible Deployment: Supports advanced Layer 2 management (VLAN, QoS, IGMP Snooping, STP) combined with desktop/rackmount versatility for secure, robust business network performance.
Port Standards
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
802.3bz 2.5G/5GBase-T Ethernet
802.3x Full-Duplex Flow Control
Network Port – Multi-Gigabit Ethernet Ports
8×100/1000/2500 Mbps Ports
Network Port – SFP+ Ports/Network Port – RJ45 Ports
2x SFP+ Ports
Switching Capacity
80Gbps
SDRAM
512MB
Flash Memory
128MB
PoE Capable Ports
Ports 1-8 (802.3af/at)
Total PoE Budget
114w
Power Source
100 to 240 VAC, 50/60Hz
Temperature Range
Operating: 32°F to 104°F (0°C to 40°C)
Humidity (Non-Condensing)
Operating: 10% – 95%
Device Dimensions & Weights
Weight: 1.65Ibs (748.8 g)
Width: 9.45” (240 mm)
Length: 4.13” (105 mm)
Height: 1.06” (27 mm)
Package Contents
1x Cloud Managed Gigabit Switch
1x Product Card
1x Power Adapter
1x Power Cord
1x Wall Mount Kit
1x Rubber Feet Cushion
