• WiFi 6 technology for high-performance and efficiency Wi-Fi in outdoor environments

• Beamforming optimizes antenna signal, reception & reliability for clients

• 2x2 directional antennas to support up to 1,200 Mbps in 5-GHz

• High 26 dBm transmit power extends Wi-Fi to yard or building-to-building

• High gain 19 dBi Integrated directional antenna extend wireless networks up to 5 miles point-to-point

• IP55-rated weatherproof & dustproof housing

• Simple, Intuitive interface via EnWiFi app for local AP configuring & monitoring

• Flexible Operation Modes: Access Point, Station, WDS Access Point, WDS Station

• Gigabit Ethernet PoE port supports flexible power options

Standards
IEEE 802.11ax on 5 GHz
(Backward compatible with 802.11b/g/n/ac)

Processor
Qualcomm® Quad-Core ARM Cortex A53s @ 1.0GHz CPU

Antenna
5 GHz (Port 1)
- Average Antenna Gain: 19 dBi
- Polarization: Linear
- Azimuth Beam Width: 30°
- Elevation Beam Width: 18°
- VSWR: 1:2.0
5 GHz (Port 2)
- Average Antenna Gain: 19 dBi
Polarization: Linear
- Azimuth Beam Width: 18°
- Elevation Beam Width: 30°
- VSWR: 1:2.0

Physical Interface
2 x 10/100/1000 BASE-T, RJ-45 Ethernet Port
1 x Reset Button

LED Indicators
1 x Power
1 x LAN 1
1 x LAN 2
1 x WLAN
1 x Signal

Power Source
EPA5006GP PoE Injector

Maximum Power Consumption
12.5W

Surge Protection
Line to Line: 1 KV
Line to Ground: 2 KV

ESD Protection
Contact: 4 KV
Air: 8 KV

Operating Frequency
Single-Radio 5 GHz

Operation Modes
Access Point, Station, WDS Access Point, WDS Station

Frequency Radio
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz

Transmit Power
Up to 26 dBm on 5 GHz

Tx Beamforming (TxBF)
Increasing signal reliability and transmitting distance

Radio Chains/Spatial Stream
2x2:2

SU-MIMO
Two (2) spatial stream SU-MIMO for 5GHz up to 1,200 Mbps wireless data rate with VHT80 to a single 2x2 wireless client device under 5GHz radio

MU-MIMO
Two (2) spatial streams multiple (MU)-MIMO for up to 1,200 Mbps wireless data rate to transmit to two (2) stream MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously

Supported Data Rates (Mbps)
5 GHz: 18 to 1200 (MCS0 to MSC11, NSS = 1 to 4)
802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)
802.11n: 6.5 to 300 Mbps (MCS0 to MCS15)
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54

Supported Radio Technologies
802.11ax: Orthogonal Frequency Division Multiple Access (OFDMA)
802.11ac/a/g/n: Orthogonal Frequency Division Multiple (OFDM)

Channelization
802.11ax supports high efficiency (HE) —HE 20/40/80 MHz
802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz
802.11n supports high throughput (HT) —HT 20/40 MHz
802.11n supports very high throughput under the 2.4GHz radio –VHT40 MHz (256-QAM)
802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU

Supported Modulation
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11b: BPSK, QPSK, CCK

Multiple BSSID
8 SSIDs for 5GHz radios

VLAN Tagging
Supports 802.1q SSID-to-VLAN Tagging
Management VLAN

Spanning Tree
Supports 802.1d Spanning Tree Protocol

QoS (Quality of Service)
IEEE 802.11e compliant
WMM

SNMP
v1, v2c, v3

MIB
I/II, Private MIB

Wireless Security
WPA3 Enterprise
WPA3-PSK (SAE)
WPA3/WPA2-PSK Mixed
WPA2 Enterprise
WPA2 AES-PSK
Hide SSID in Beacons
Client Isolation

Temperature Range
Operating: -4ºF~140ºF (-20ºC~60ºC)
Storage: -40ºF~176 ºF (-40ºC~80ºC)

Humidity (non-condensing)
Operating: 90% or less
Storage: 90% or less

EnStation6 Device
Weight: 558 g
Depth: 190 mm
Height: 38 mm

EnStation6 Packaging
Weight: 2.47 lbs. (1.21 kg)
Length: 12.63" (321 mm)
Width: 9.72" (247 mm)
Height: 3.46" (88 mm)

Package Contents
1 x EnStation6 Outdoor Wireless Bridge/Access Point
1 x PoE Injector (EPA5006GR)
1 x Power Cord
2 x Pole Mount Brackets
1 x Wall Mount Screw Kits
1 x Product Card

Certifications
FCC
CE
IC

Warranty
2 Years
